- Nominal Impedance : 4 Ohms
- Sensitivity : 90dB (2.83V/ 1m)
- Frequency Response : 40Hz - 28kHz (±6dB) open backed
- Crossover Frequencies : 400Hz, 2.8kHz
- Drive Units : LF: 4 x 160mm (6.5 in.), MF: 125mm (5.25 in.) Uni-Q, HF: 25mm (1 in.)
- Recommended Amplifier Power : 40 - 500W
- Features : Uni-Q Array
- Product External Dimension (H X W X D) : 1070 x 230 x 105.7 mm (42.13 x 9.06 x 4.16 in.)
- Cut-out Dimensions (H X W) : 1052 x 209mm (41.42 x 8.23 in.)
- Mounting Thickness : Ceiling Thickness (Maximum): 40mm (1.58 in.), Ceiling Thickness (Minimum): 6mm (0.24 in.)
- Mounting Depth From Surface : 99mm (3.9 in.)
