Details
Premium 9.4 channel 125-watts-per-channel amplification, Dolby Atmos, DTS:X Auro 3D, and 8K Ultra HD plus HEOS® Built-in streaming. CINEMA 40 is a statement piece and reference level A/V Receiver.
Number of Powered Channels : 9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) : 125 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) : 165 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) : 235 W
Discrete Power Amplifier : Yes
Amplifier Topology : Class A/B
Bi-Amp Drive : assignable
DTS : DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby : Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other : IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG H, Audyssey DSX, Multichannel Stereo 2
Max Number of Processing (Preamp) Channels : 11.4
Composite In / Out : 2 / 0
Component In / Out : 1 / 0
HDMI In / Out : 7 / 3
Multi-Room Video Out via HDMI : Yes
Analog In / Fixed Level Out : 5 in / 0 out
Phono (MM) In : Yes
Digital In: Optical / Coaxial : 2 / 2
Multi-Room Out: analog / digital : 2 / 0
Multichannel Preamp Out : 11.4
Subwoofer Out : 4 (independent)
7.1 multichannel input : No
Number of Speaker Terminals : 11
Speaker A / B : assignable
Multi-Room Speaker Terminal : assignable
Front Inputs : USB-A
USB Audio / Made for iPod / Made for iPhone : Yes / No / No
AM/FM Tuner : Yes
Total HDMI Inputs / No. Support 8K : 7 / 7
HDCP2.3 support : Yes
HDMI Outputs: Main / Zone : 2 / 1
Analog to HDMI Video Conversion : Yes
HDMI Upscaling : 1080P/4K to 8K
Max resolution @ framerate : 8K @ 60Hz, 4K @ 120Hz
Audio Return Channel : ARC, eARC
Video Dynamic Range : HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming : Yes
Variable Refresh Rate / Quick Frame Transport : Yes / Yes
HDMI Pass-Through in Standby Mode : Yes
CEC : Yes
DSD Audio over HDMI : Yes
Auto LipSync : Yes
Hyper Dynamic Amplifier Modules (HDAM) (List version) : Yes
Pure Direct Mode : Yes
Gold Plated RCA Terminals : Yes
Clock Jitter Reducer : Yes
HEOS Multi-room and Streaming : Yes
AirPlay Audio Streaming : Airplay 2
Internet Radio : TuneIn
Spotify : Spotify Connect
Pandora : Yes
SiriusXM : Yes
Other Streaming Services : Amazon Music HD/
Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
